8KW 3 Phase 20KWH Wall Lifepo4 Battery Hybrid Solar System
System Type: 8KW 20KWh Hybrid 3 phase
Battery: 20.48KWh lifepo4 powerwall battery
Output Voltage: 230VAC ± 5% @50/60Hz
Certificate: CE/TUV/CSA/CEC/UL/ISO
Lead Time:7-10 days
Payment: T/T, Credit Card, Paypal, Western Union
Place of origin: China
Description
8KW 3 Phase 20KWH Wall Lifepo4 Battery Hybrid Solar System
The hybrid solar system 8KW is a three phase low voltage hybrid system with a 20kwh lifepo4 powerwall battery, can generate about 30.8KWh per day if there are four efficient hours of sunlight. Compared to the 8KW 3 phase 10kwh lifepo4 battery hybrid solar system, this system is more suitable for houses with 5 to 7 people when need more electricity use at night, small commercial and industries.
What does HBOWA offer with the hybrid solar system?
HBOWA supports you with designing the whole hybrid solar system solutions for free. We have comprehensive certificates for the hybrid system and have no requirements for MOQ. We provide a 12-year warranty for solar panels and 5 years for hybrid solar inverters and lifepo4 batteries. For technical support, we provide service via WhatsApp/email/WeChat, and we have operation guide videos on our YouTube channel to guide you on how to use our solar products, our technicians shall go to your place to guide you if necessary.
Technical Data
- DATA
| 8KW Three Phase Low Voltage Hybrid Solar Power System Components | ||||
| Item | Name | Description | Quantity | Warranty |
| 1 | Solar Panel | PERC 550w Mono | 14 pcs | 25 years |
| 2 | Inverter | 8kw Hybrid three phase solar inverter | 1 set | 5 years |
| 3 | PV Combiner Box | customized according to the solar system | 1 pc | 5 years |
| 4 | Battery | 20kwh powerwall lifepo4 battery | 1 set | 5 years |
| 5 | Solar Mounting Structure | Roof/Ground Install(Customized) | 1 set | 10 years |
| 6 | PV Cable | 4 mm2 DC PV Cable | 200m | 10 years |
| 7 | MC4 | MC4 Connector | 16pcs | – |
| 8 | Standard Wooded Package + System Connecting Drawings (Easy Installing) | |||
| 9 | System Capacity could be adjustable according to the customer’s situation | |||
Components
Mono-crystalline Solar panel
Mono-crystalline PERC Solar panel
* 144 mono solar panel cells;
* 182mm mono PERC type;
* Power 550W 560W 570W 580W available;
* Maximum efficiency to 21.29%;
* Brand panel available: Longi/JA/Jinko/Trina
Hybrid Three Phase Inverter
8KW On grid and off grid three phase solar inverter
* Pure sine wave, high frequency
* Smart Battery Management
* LCD colored touch screen display
* Over load/ short circuit protection
10KWh LifePO4 Battery
10kwh powerwall lifePO4 battery *2
* Over 6000 cycle times and high energy density
* The built in BMS ensures high safety and stability.
* Easy installation and space-saving.
* The ingress protection rate is IP20(IP65 optional).
Mounting Structure for Solar Panel
Our ground solar mounting structures are all aluminum steel materials. They are designed to withstand various environmental conditions, ensuring long-term stability and durability. The system’s lightweight design minimizes roof load, while its pre-assembled components significantly reduce installation time and labor costs.
Solar System Accessories
* Combiner box with voltage resistance of 500V;
* PV single core cable 4m㎡,6m㎡,10m㎡ etc;
* MC4 connectors, according to solar panels.
If your customers need any other accessories, feel free to tell us.
